Today’s melt shop is under increasing pressure to improve productivity, temperature control, metal cleanliness. A broad range of monolithic and precast products are available and Foseco personnel are on hand to offer advice on product selection, maintenance and design.
KALTEK Insulating Ladle Lining Systems
KALTEK insulating lining materials provide superior performance with respect to heat loss, energy usage, and metal quality in metal transfer vessels and are available in a variety of forms.
- Preformed Boards Systems
- Preformed One-Piece Linings
- Castable Powders
- Ladle Lids
KALTEK benefits:
- Reduced casting defects
- Increased productivity
- Improved metallurgical process consistency
- Reduced labor
- Lower energy consumption
- Cold start capability
Conventional Dense Ladle Linings
Primary lining materials:
- CRITERION low cement castables
- DURAFLO self-flow castables
- TRIAD cement-free castables
- ONYX silicon carbide low cement castables
Ancillary and repair materials:
- DURACRETE, BLU-RAM, X-9 phosphate bonded plastics
- KALSEAL, SUREBOND, SUPER #3000 Alumina Silicate mortars
Coreless Induction Furnace
Primary lining:
- KELLUNDITE 700 andalusite based dry vibratable
- SILCOR fused silica enriched quartzite dry vibratable
- FINMIX quartzite based dry vibratable
Capping and spout:
- BLU-RAM HSW and DURACRETE RBG granular phosphate bonded plastic materials for furnace capping and spouts
Coil protection:
- COILCOTE and KELLUNDITE G alumina based, cement bonded grouts
Slip plane:
- COIL PROTECT 035 W-P 0.4 mm woven glass phlogopite mica
- COIL PROTECT 240 CW-P 2.4 mm woven glass phlogopite mica
Cupolas
Well, siphon box, tap hole and slag hole:
- TRIAD Z-189 high performance sol bonded castable based on white fused alumina with additions of silicon carbide and carbon for superior erosion resistance.
- RAMWELL high alumina, pitch free granular ramming enriched with SiC
- HYDRA-MAX high alumina, ultra-low cement castables, containing silicon carbide for superior slag resistance
- SURGUN low cement, gunned castables ideal for repair and maintenance
Melting zone:
- ULTRAGUN SC55 high silicon carbide gunning material
Gas offtake:
- ULTRAGUN 1600 low cement gunning material resistant to high temperature reducing conditions
Shaft:
- CRITERION low cement castables
- DURAGUN low cement gunning
Channel Melting and Holding Furnaces
Primary lining:
- KELLUNDITE high alumina dry-vibratable refractory materials for furnaces holding iron
- CRITERION high alumina, low cement castable refractories for furnaces holding iron
- SPINCAST high alumina, spinel castables for enhanced slag resistance
Inductors:
- MAGNAVIBE spinel-forming magnesia based dry-vibratable material for high powered inductors
- KELLUNDITE spinel-forming alumina based dry vibratable material used as a universal inductor lining
Capping material:
- CRITERION 50ME used as a capping material for the top 200mm of the dry lined furnace body
Spouts and receiver:
- BLU-RAM and 90 RAM phosphate bonded ramming mixes
Repairs:
- ULTRAGUN SC55 high silicon carbide gunning material
Autopour Furnaces
Primary linings:
- CRITERION high alumina, low-cement castables
- SPINCAST high alumina, spinel containing castables for increased slag resistance
Spouts:
- DURAFLO high alumina, self-flow castable
Inductors:
- MAGNAVIBE spinel-forming magnesia based dry-vibratable material for high powered inductors.
- KELLUNDITE spinel-forming alumina based dry vibratable material used as a universal inductor lining.
Covers:
- CERCAST high alumina conventional castable
- LITEWATE insulating castables
VAPEX Stoppers and Nozzles
VAPEX standard and plunger rod stoppers are ideal for autopouring units in iron foundries and are designed for long campaign and multi open / close sequences.
VAPEX ceramic / carbon bonded alumina graphite nozzles are available in standard taper and reverse taper designs and are ideally suited for autopour applications.
VAPEX cross bore nozzles produce a smooth, concentrated pouring stream and offer significant benefits over conventional designs.
